Liberty AV Solutions DigitalinxIP 2200 Series 1G AV/IP Encoder

DigitalinxIP 2200 Series AV/IP Encoder

H.264/H.265 AV over IP 1080p Encoder with video wall support for scalable and flexible distribution.

Key Features

• Transmits HDMI video and audio over a 1Gb network infrastructure using H.264/H.265 encoding with data rates up to 30 Mbps
• Supports video resolutions up to 1080p @ 60 Hz
• Analog audio output port de‑embeds audio from HDMI content while also streaming audio within the IP video feed
• Supports video wall configurations for flexible multi‑display layouts
• Enables control of third‑party devices via RS232
• Supports Power over Ethernet (PoE)
• Backward compatible with all 2100 Series DigiIP products for general video distribution applications
• Note: For video wall applications, the entire configuration must consist of either 2100‑series or 2200‑series devices only

Applications

• Video Distribution
• Digital Signage
• Restaurants, Bars, Entertainment Venues
• Hospitality Environments
• Large‑Scale HDMI Distribution
• Video Wall Installations
